Asia's first Compact mineral water dispenser machine (UV+Ozone+RO )
Additional water pump can be attached if required
Pure clean drinking water dispenses with normal hot and cold options.
100% automatic electronic controller with RO units may be attached inside with Ultraviolet purifier
Our products can be availed in customized range as per the specifications and requirements of our clients.(Normal, Hot, Cold)
Available in 50lph , 75lph , 100lph ,125lph and 250 9 tap models
Made in India Product
| USAGE MODEL | |||||
| MODEL | 50 | 75 | 100 | 125 | 250 |
| NO OF PEOPLE | 0 to 10 | 10 to 30 | 30 to 50 | 50 to 80 | 80 to 100 |
| Usage | CORPORATION / MUNICIPAL WATER | ||||
| Model | Aguaclan | ||||
|---|---|---|---|---|---|
| 50C | 75C | 100C | 125C | 250C | |
| Water Capacity | 20 | 30 | 50 | 80 | 100 |
| No of Taps | 2 | 2 | 2 | 2 | 6 |
| Dimensions | 785*365*355 mm | 1300*365*355 mm | 1370*455*450 mm | 1470*555*525 mm | |
| Materiel of Construction | Housing: Stainless Steel SS 202 / 304 and 0.8mm thickness | ||||
| Water Tank | LLDPE Food Grade or Stainless Steel 304 | ||||
| Frame | Stainless Steel 1.2mm thickness frame with SS legs with adjustable bush | ||||
| Cold Temparature Range | 16C - 22C | ||||
| Model | Aguaclan | ||||
|---|---|---|---|---|---|
| 50N | 75N | 100N | 125N | 250N | |
| Water Capacity | 22 | 30 | 50 | 80 | 100 |
| No of Taps | 2 | 2 | 2 | 2 | 6 |
| Dimensions | 785*365*355 mm | 1300*365*355 mm | 1370*455*450 mm | 1470*555*525 mm | |
| Materiel of Construction | Housing: Stainless Steel SS 202 / 304 and 0.8mm thickness | ||||
| Water Tank | LLDPE Food Grade or Stainless Steel 304 | ||||
| Frame | Stainless Steel 1.2mm thickness frame with SS legs with adjustable bush | ||||
| Cold Temparature Range | - | ||||
| Model | Aguaclan | ||||
|---|---|---|---|---|---|
| 75NC | 100NC | 125NC | 250NC | ||
| Water Capacity | N - 14 Ltrs / C - 14 Ltrs | N - 20 Ltrs / C - 20 Ltrs | N - 40 Ltrs / C - 40 Ltrs | N - 40 Ltrs / C - 40 Ltrs | |
| No of Taps | 2 N and C | 6 N and C | |||
| Dimensions | 1300*365*355 mm | 1370*455*450 mm | 1470*555*525 mm | ||
| Materiel of Construction | Housing: Stainless Steel SS 202 / 304 and 0.8mm thickness | ||||
| Water Tank | LLDPE Food Grade or Stainless Steel 304 | ||||
| Frame | Stainless Steel 1.2mm thickness frame with SS legs with adjustable bush | ||||
| Cold Temparature Range | - | ||||
| Model | Aguaclan | ||||
|---|---|---|---|---|---|
| 50NH | 75NH | 100NH | 125NH | 250NH | |
| Water Capacity | N - 22 Ltrs / H - 3 Ltrs | N - 30 Ltrs / H - 3 Ltrs | N - 50 Ltrs / H - 5 Ltrs | N - 80 Ltrs / H - 5 Ltrs | N - 100 Ltrs / H - 5 Ltrs |
| No of Taps | 2 N and H | ||||
| Dimensions | 785*365*355 mm | 1300*365*355 mm | 1370*455*450 mm | 1470*555*525 mm | |
| Materiel of Construction | Housing: Stainless Steel SS 202 / 304 and 0.8mm thickness | ||||
| Water Tank | LLDPE Food Grade or Stainless Steel 304 | ||||
| Frame | Stainless Steel 1.2mm thickness frame with SS legs with adjustable bush | ||||
| Cold Temparature Range | 50C - 75C | ||||
| Model | Aguaclan | ||||
|---|---|---|---|---|---|
| 75NHC | 100NHC | 125NHC | 250NHC | ||
| Water Capacity | N - 14 Ltrs / H - 3 Ltrs / C - 14 Ltrs | N - 20 Ltrs / H - 5 Ltrs / C - 20 Ltrs | N - 40 Ltrs / H - 5 Ltrs / C - 40 Ltrs | N - 40 Ltrs / H - 5 Ltrs / C - 40 Ltrs | |
| No of Taps | 3 | 6 | |||
| Dimensions | 1300*365*355 mm | 1370*455*450 mm | 1470*555*525 mm | ||
| Materiel of Construction | Housing: Stainless Steel SS 202 / 304 and 0.8mm thickness | ||||
| Water Tank | LLDPE Food Grade or Stainless Steel 304 | ||||
| Frame | Stainless Steel 1.2mm thickness frame with SS legs with adjustable bush | ||||
| Cold Temparature Range | 50C - 75C | ||||
