Filters are made with highly durable, food-grade material and have self cleaning capabilties to auto-flush out debris.
360 degree union rotation capability make these filters suitable for any site conditions. Easily wall mounted, self installable with easy to understand instructions make it user friendly.
Our filters work on the principle of cohesion & centrifugal force. This enables filtering at variable intensity of rainfall without affecting the efficiency.
Various models available to suit rooftop areas ranging from 110 sqm to 500 sqm. The collected water can be diverted to underground sump, existing borewell or other water reservoirs.
Works on Gravitational Force and does not require any external energy. Low gravitational head of just 1 feet makes it feasible for installation on any building.
Filters have no moving parts, eliminating any wear and tear. This makes them long lasting with only one time economical purchase cost.
| MODEL | 800 - 1300 Sq. Ft. | 2000 - 2500 Sq. Ft. | 3000 - 4000 Sq. Ft. |
| Model | Aguaclan - Rain Water Filter 80 Model |
|---|---|
| RAIN WATER FILTER 80 MODEL | QTY |
| Suitable for Area | Up to 120 SQMTRS |
| Intensity of Rainfall | 5 mm/Hour to 75 mm/Hour |
| Filter Type | Open ended, Non-clog |
| Working Principle | Cohesive Force & Centrifugal Force |
| Operating Pressure | 1 foot of Gravity Head (0.060kg/cm2) |
| Max Discharge at (CWO) | 120 Liters per minute |
| Filter Element | SS-304 Multi-Surface Screen - Food Grade |
| Mesh Size | 250 Microns |
| Inlet Size | 90 MM |
| Clean Water Outlet size (CWO) | 63 MM |
| Drain Outlet size | 90 MM |
| Filter Housing | UV Stabilized - HDPE |
| Filter Efficiency | Above 90%* |
| Source of Power | Gravity |
| Model | Aguaclan - Rain Water Filter 150 Model |
|---|---|
| RAIN WATER FILTER 150 MODEL | QTY |
| Suitable for Area | Up to 180 SQMTRS |
| Intensity of Rainfall | 5 mm/Hour to 75 mm/Hour |
| Filter Type | Open ended, Non-clog |
| Working Principle | Cohesive Force & Centrifugal Force |
| Operating Pressure | 1 foot of Gravity Head (0.060kg/cm2) |
| Max Discharge at (CWO) | 180 Liters per minute |
| Filter Element | SS-304 Multi-Surface Screen - Food Grade |
| Mesh Size | 250 Microns |
| Inlet size | 90 MM |
| Clean Water Outlet size (CWO) | 75 MM |
| Drain Outlet size | 90 MM |
| Filter Housing | UV Stabilized - HDPE |
| Filter Efficiency | Above 90%* |
| Source of Power | Gravity |
| Model | Aguaclan - Rain Water Filter 250 Model |
|---|---|
| RAIN WATER FILTER 250 MODEL | QTY |
| Suitable for Area | Up to 250 SQMTRS |
| Intensity of Rainfall | 5mm/Hour to 75 mm/Hour |
| Filter Type | Open ended, Non-clog |
| Working Principle | Cohesive Force & Centrifugal Force |
| Operating Pressure | 1 foot of Gravity Head (0.060kg/cm2) |
| Max Discharge at (CWO) | 250 Liters per minute |
| Filter Element | SS-304 Multi-Surface Screen -Food Grade |
| Mesh Size | 250 Microns |
| Inlet size | 110 MM |
| Clean Water Outlet size (CWO) | 90 MM |
| Drain Outlet size | 90 MM |
| Filter Housing | UV Stabilized - HDPE |
| Filter Efficiency | Above 90%* |
| Source of Power | Gravity |
| Model | Aguaclan - Rain Water Filter 300 Model |
|---|---|
| RAIN WATER FILTER 300 MODEL | QTY |
| Suitable for Area | Up to 350 SQMTRS |
| Intensity of Rainfall | 5 mm/Hour to 75 mm/Hour |
| Filter Type | Open ended, Non-clog |
| Working Principle | Cohesive Force & Centrifugal Force |
| Operating Pressure | 1 foot of Gravity Head (0.060kg/cm2) |
| Max Discharge at (CWO) | 340 Liters per minute |
| Filter Element | SS-304 Multi-Surface Screen - Food Grade |
| Mesh Size | 250 Microns |
| Inlet size | 110 MM |
| Clean Water Outlet size (CWO) | 110 MM |
| Drain Outlet size | 90 MM |
| Filter Housing | UV Stabilized - HDPE |
| Filter Efficiency | Above 90%* |
| Source of Power | Gravity |
| Model | Aguaclan - Rain Water Filter 500 Model |
|---|---|
| RAIN WATER FILTER 500 MODEL | QTY |
| Suitable for Area | Up to 500 SQMTRS |
| Intensity of Rainfall | 5 mm/Hour to 75 mm/Hour |
| Filter Type | Open ended, Non-clog |
| Working Principle | Cohesive Force & Centrifugal force |
| Operating Pressure | 1 foot of Gravity Head (0.060kg/cm2) |
| Max Discharge at (CWO) | 480 Liters per minute |
| Filter Element | SS-304 Multi-Surface Screen - Food Grade |
| Mesh Size | 250 Microns |
| Inlet size | 110 MM |
| Clean Water Outlet size (CWO) | 110 MM |
| Drain Outlet size | 110 MM |
| Filter Housing | UV Stabilized - HDPE |
| Filter Efficiency | Above 90%* |
| Source of Power | Gravity |
