DOMESTIC NORMAL & HOT

DOMESTIC NORMAL & HOT

  Universal pump assembly provisions for all branded pumps (Eichen,Swann ,DMC ,Lexcru ,BNQS ,Kemflo)

  Installation is so easy with a free template of wall mounting provisions

  Theme/customer based designs can be made of with MOQ 50nos

  10 lit of normal storage tank ; 2 lit of hot storage tank (optional)

  SS 304 of 0.8mm thickness with SS support clamps

  Inbuilt with Provision of RO+UV+UF+ Alkaline combined

  High Quality stainless steel taps

  Available with SS202/304 housings

Customization Themes
Portable
User Friendly
Wall Mountable

Technical Specifications

Model Aguaclan - DOMCAB-NH
DOMCAB-NH QTY
Overall dimension 500(H) x 400(L) x 265(W) are in mm.
Taps Normal Antique Tap
Water Source Good water / RO Water
Storage Type Along With dispenser
Normal Water Storage Tank Capacity 5 L
Hot Water Storage Tank Capacity 1 L
Water Level Controller Electronic - Micro Controller Based
Method of Level Sensing Stainless Steel Probes
Heater Temperature Range 50 - 75 C'
Make of Dispenser AguaClan
Number of Faucets 2 taps
MOC Frame Stainless Steel 1.2 mm thickness.
Power Cord 16 Amps Model.
Power Supply 230-220 volts.
Heater Coil 500 Watts
MOC - Housing Stainless Steel 304 and 0.8/0.6mm thick
MOC – Faucets Stainless Steel SS 304
MOC –Storage Tank- Normal Stainless Steel SS 304 and 0.8/0.6mm thick
Storage Tank - Hot Stainless Steel SS 304 and 0.8/0.6mm thick
Plumbing Customer scope with 1/2” Ball valve
Warranty 6 months only for electrical parts
Branding Yes
Don't settle for anything less than perfection. Get your own Personalized Water solution
